Fisher 3570, 3570C, 3570P, 3571, 3572 Pneumatic Positioner

Fisher 3570, 3570C, 3570P, 3571, 3572 Pneumatic Positioner

Fisher 3570 pneumatic valve positioners are used with control valve assemblies to provide an accurate valve stem position that is proportional to the input signal received from a control device. These positioners are normally used with pneumatic piston actuators. However, product types within the 3570 family can be used with pneumatic, long-stroke, cylinder, or pneumatic diaphragm actuators.

Area Classification ATEX Group II Category 2 Gas and Dust, CUTR for Groups II/III Category 2 Equipment

Specifications

Certifications ATEX, CUTR, PED
Communication Protocol 3-15 or 6-30 psi, 0.2 -1.0 or 0.4 -2.0 bar Pneumatic Signal
Diagnostics No
Input Signal Pneumatic
Max Outlet Pressure 150 psi
Mounting Type Actuator Mounted
Operating Temperature Standard Temperature, High Temperature
Position Control Modulating
Safety Certification NIL
Supply Media Air, Natural Gas
Other Configurations Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.

Feature

• Actuator with or without positioners and snubbers is available in an assortment of sizes, stroking speeds, thrusts, and travels to handle most control requirements.
• Yokeless construction permits a low-profile assembly by allowing close coupling to the control device; either through a bracket or, with some versions, by direct mounting on a bonnet flange.
• The cylinder (and 3570 positioner if used) can operate with supply pressures as low as 2.4 bar (35 psig) or as high as 10.3 bar (150 psig).
• Actuators have maximum rated travels of up to 206 mm (8.125 inches).
• Positioner/actuator action is easily reversed in the field with no additional parts. Positioner sensitivity, travel span, and travel starting point are factory set and need to be reset only if operating conditions have changed or if the positioner has been reversed.

Input Signal
Standard Ranges: 0.2 to 1.0 bar (3 to 15 psig) or 0.4 to 2.0 bar (6 to 30 psig)
Optional Ranges: As desired, within the limits of the bellows
Split Ranges: Use one-half of either standard range when two control valves are operated by one output signal form a single control device

Output Signal
Type: Pneumatic pressure as required to maintain the correct valve stem position and seat load
Action: Field-reversible between direct and reverse

Approximate Weight
2.7 kg (6 pounds)

 We can delivery the cargo to transport company within 3 days upon receiving of the cargos from the plant
Any question, please do not hesitate to contact me.

1.Swift delivery

 For common parts, we can deliver the goods within 3 days

2.Original products

 All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.

3.Quality Assurance

4.Technical Support

 Including inspection,repair and maintenance, we can give all kinds of technical support.

5.Quickly responce

 Our staffs will keep 24h online and answer your question very quickly.

 Xiangjing(Shanghai)M&E Tech. Co., Ltd is a valve and instrument distributor for a series of world-wide famous brands just like Emerson,Fisher,Rosemount,Masoneilan,Flowserve,Rotork,etc.
We have many common models in stock, so that we can offer our service in very short time.
Our office is located in Shanghai, we welcome your visit!

Q.How long will you need before delivery?

A:We have many common models in stock, so that we can deliver the goods very soon(less than 3 days).

Q.What is your payment term?

A:Normally T/T 30% in advance, balance to be paid before delivery, We also support the trade assurance,O/A.

Q:What is Trade Assurance?

A:Trade Assurance is a free service by Alibaba.com that’s designed to help create trust between buyers and suppliers. Trade Assurance helps buyers in the event of shipping and quality-related dispute.

Q:Does Trade Assurance charge fees?

A:No. Trade Assurance is free for both buyers and suppliers.

Q:What kind of trade terms can you do?

A:EX-WORKS,FOB,CFR,CIF,etc.
