One of the key features of this product is its compliance voltage. It requires a voltage range of 9 Vdc at 20 MA to 11 Vdc at 4 MA. This ensures that it operates consistently and reliably, providing precise control over the valve even under varying conditions.
The Control Valve Positioner is also highly customizable, making it an ideal choice for OEM applications. It can be configured to meet specific requirements and can be integrated seamlessly into existing systems, making it an excellent choice for automation projects of any size.
As a Control Positioner Actuator, this product has a wide range of applications in various industries, including oil and gas, chemical processing, and power generation. Its ability to provide accurate control over the valve makes it an essential component in many different systems and processes.
Another key attribute of the Control Valve Positioner is its min/max current range. It requires a current range of 3.2 MA to 24 MA, ensuring that it can handle a wide range of operating conditions and maintain consistent performance. This makes it an ideal choice for use in harsh environments and demanding applications.
The Control Valve Positioner is also designed to operate in high humidity environments, with humidity limits of up to 100% RH non-condensing. This ensures that it can operate effectively even in conditions where moisture and humidity levels are high.
In summary, the Control Valve Positioner is a Control Positioner Actuator that is designed to deliver precise control over valve systems. Its compliance voltage, customizable support, min/max current range, and high humidity limits make it an excellent choice for a wide range of applications in various industries.
| Technical Parameter | Value |
|---|---|
| Product Name | Masoneilan Valve Positioner |
| Humidity Limits | 100% RH Non-condensing |
| Termination | Screw-type Terminals |
| Warranty | 1 Year |
| Electrical Connection | One 1/2NPT Female |
| Required Compliance Voltage | 9 Vdc At 20 MA 11 Vdc At 4 MA |
| Ambient Temperature | -40 To 85°C (-40 To 185°F) |
| Std. Materials | Cast Iron, Carbon Steel, Stainless Steel, Monel |
| Min/Max Current | 3.2 MA/24 MA |
| Brand Name | Masoneilan |
The Control Valve Positioner is an essential component in any process control system that requires precise control of valve position. It is used to control the flow of fluids, gases, and other materials in pipelines. The positioner works by receiving a control signal from the process control system and then adjusting the position of the control valve actuator to maintain the desired flow rate.
The Masoneilan Valve Positioner is suitable for use in a wide range of applications such as oil and gas, chemical, petrochemical, power generation, and many others. It is designed to work with different types of control valves, including rotary and linear valves, and can be used in both high and low-pressure applications.
The Control Valve Positioner is an essential component in the control system of any industrial process. It provides accurate control of valve position, which is critical for maintaining the desired flow rate and ensuring the safety of the process. The Masoneilan Valve Positioner is a high-quality product that is built to last and is suitable for use in a variety of applications.
The Masoneilan Valve Positioner comes with various features such as electrical connection of one 1/2NPT Female, termination of screw-type terminals, and min/max current of 3.2 MA/24 MA. The product can be ordered with a minimum order quantity of 1 and costs between 1480USD~2000USD. It comes with packaging details of wooden box/carton box and has a delivery time of 6~8 working weeks. Payment terms are T/T, and the product has a supply ability of 100Sets/Month.
In conclusion, the Masoneilan Valve Positioner is an essential component of any control system that requires precise control of valve position. It is a high-quality product that is designed to meet the highest industry standards and is suitable for use in a wide range of applications. The product is available in different models and comes with various features that make it a reliable valve position regulator.
Brand Name: Masoneilan
Model Number: SVI1000/SVI2/SVI3
Place of Origin: Germany
Certification: -
Minimum Order Quantity: 1
Price: 1480USD~2000USD
Packaging Details: Wooden box/Carton box
Delivery Time: 6~8 working weeks
Payment Terms: T/T
Supply Ability: 100Sets/Month
Product: Control Valve Positioner
Humidity Limits: 100% RH Non-condensing
Customized support: OEM
Min/Max current: 3.2 MA/24 MA
Electrical connection: One 1/2NPT Female
